    LSM300 Parallelogram Load Cell

    € 398,-
    € 378,10 Excl. btw Email of bel ons voor de levertijd
    LSM300 , Parallelogram Load Cell , RoHS Compliant , Material - 2024-T4 , #10-32-Thread , Overload Protection , 29 Awg 4 Conductor Spiral Teflon Cable , 6 in Long... Toon meer
    7 variaties FSH03974 - 2.2lb (9.8N)
    • Your reliable partner since 21 years
    • Shipping from our own warehouse !
    • Secure shipping in EU with DPD Traceable
    • Questions : Call +31-(0)85-065 6325

    Productomschrijving

    Download Datasheet Download PDF

    The LSM300 Precision Load Cell also known as the Belt Buckle Load Cell offers an impressive lightweight design with an easy side mounting feature making it ideal for OEM applications. Utilized in both Tension and Compression, the Precision Load Cell has a length of 1.80”, width of 0.50” and with a height of 1.40” it is well suited for any tight spaces. The LSM300 Precision Load Cell is offered in 2024 Aluminum (2.2 – 100 lbs) or 17-4PH Stainless Steel (200 – 500 lbs) and it has a 6” 29 AWG 4 color coded Teflon lead wire.

    Additional design features includes a built in overload protection providing the unit over 10 times the capacity that could take place during installation. As a part of FUTEK’s original product line, the Precision Load Cell can be modified or customized to meet your requirements and most standard capacities are available in our inventory, making it available for 24 hour shipping. Similar to our entire Load Cell product line this model is manufactured in the US and uses metal foil strain gauge technology.

    Features

    • Intended for high volume applications
    • Easily integrates into OEM applications
    • Built-in overload protection
    • Exceptional nonlinearity and nonrepeatability
    • Can integrate with analog VDC, mA, digital SPI, I2C, RS-232, UART output, and more



    Specificaties

    Artikelnummer
    FSH03974 - 2.2lb (9.8N)
    SKU
    FSH03974 - 2.2lb (9.8N)
    LSM300 Parallelogram Load Cell
    € 398,-
    € 378,10
    Excl. btw
    LSM300 Parallelogram Load Cell
    FSH03974 - 2.2lb (9.8N)
    Email of bel ons voor de levertijd
