Ethernet I/O Module/Modbus TCP/4AO/5DI/5DO
Ethernet TCP to Analog output Module
4 analog output channels, 0-10 VDC or 0~20 mA
5 digital input channels (dry or wet contact)
5 isolated digital output channels (open collector)
Configuration, monitoring, and visualisation with standard Webbrowser
Communication Protocol: Modbus UDP/TCP
Operating Temperature: -25 ~ +75 °C
Power Supply: 10-30 VDC (ET-7024) or 12-48VDC / POE (PET-7024)
DIN-Rail Mounting
The ET-7024/PET-7024/ET-7224/PET-7224 is a multifunction module includes 4 channels analog output, 5 channels digital input and 5 channels digital output. It provides a variety of programmable analog output options (+/-5 V, +/-10 V, 0 ~ 20 mA and 4 ~ 20 mA), and each analog output can be programmed to accept either current or voltage as output depending upon the position of corresponding jumper. The ET-7024/PET-7024/ET-7224/PET-7224 is fully RoHS compliant and provides 4 kV ESD protection as well as 2500 VDC intra-module isolation.
